What is the difference between high-speed rapier looms and Shaoxing jet edge looms and their fabrics? Fabric differentiation: To determine whether the fabric is sword woven or jet woven, one can look at the edge structure of the fabric: usually polyester cotton thread is a rapier (locking edge device), and filament is jet woven (planetary gear device). Jet double open fabric, with one side being thread and the other side being filament. (The middle is a locking device, with planetary gears installed on both sides). The high-speed rapier loom is used for double opening fabrics, with polyester cotton thread on both sides (both with locking devices).

　　Loom differentiation: High speed rapier weaving machine: using rigid or flexible rapier heads, straps for clamping, and guiding weft yarn. The high-speed rapier loom is not only suitable for weaving plain and textured fabrics, but also has the characteristics of convenient color changing, suitable for multi color weft fabrics, and suitable for the production of color woven, double-layer velvet fabrics, loop fabrics, and decorative fabrics. Shaoxing jet edging machine: uses compressed airflow to pull the weft yarn and take it through the shuttle. The biggest feature of Shaoxing jet edge machine is its fast speed and high labor productivity, which is suitable for plain and textured fabrics, fine and high-density fabrics, and bulk fabrics.

Advantages and disadvantages of grey fabric: The Shaoxing jet edging machine generally produces a variety of fine count yarns with higher grades, mainly for light and thin fabrics; Rapier machines generally have a wide variety of coarse count yarns with lower grades, mainly for heavy fabrics. From the perspective of equipment, the Shaoxing jet edging machine and the high-speed rapier weaving machine are nothing but different in weft insertion. When weaving the same fabric, the raw material cost is the same, and the weaving cost is relatively low for jet weaving. For example, in the case of diagonal weave, the maximum speed of the Shaoxing jet smooth edge locomotive can reach 800 rpm or more, and the rapier only has about 180-200 rpm. The jet blocking personnel can view 10-12 units per person, while the high-speed rapier weaving machine can only have 4-6 units at most.

　The commonality and heterogeneity of fabrics, commonality: all are burrs and can be of the same specifications. Heterogeneity: Under the premise of the same yarn count and specifications, the weight of Shaoxing Jet Smooth Edge Machine is slightly lighter. The flatness of plain fabric produced by Shaoxing jet edge machine is better than that produced by high-speed rapier weaving machine. The fabric shrinkage of Shaoxing jet edging machine will be correspondingly higher. The quality of yarn used in Shaoxing jet edging machine is better than that of rapier.
